Oem Customized Transmission Detent Cable End Clip Wire Rope Clamp Wire Looper
|Place of Origin:||Dongguan,China|
Payment & Shipping Terms:
|Minimum Order Quantity:||1000pcs|
|Packaging Details:||PE bag +PP bag + carton (if you have other requirements, please contact us)|
|Delivery Time:||10-15Work Days|
|Payment Terms:||T/T, Western Union|
|Product Name:||Cable Clip Wire Rope Clamp Cable Gripper||Material:||Brass|
|Cable Construction::||7x7 Or 7x19||Application:||Lighting,hanging|
|MOQ:||1000pcs||Lead Time:||7 Days If There Were Enough Material In Stock|
|Sample:||Free Sample (Please Contact Our Customer Service)|
Customized Transmission Detent Cable End Clip,
Looper Wire Cable Grippers,
Detent Cable Wire Rope Clamp Looper
Feature of Cable Clip Wire Rope Clamp Cable Gripper
Cable gripper, (also called cable slider or cable fastener):
Metallic component, cylindrical, external dimensions according to Annex 2, capable of gripping a wire rope of 7 x 7 wires via 3 sphere locking system. Grips cable when sliding in one direction and releases it on opposite direction. After cable is inserted provides no access to locking mechanism and no possibility of tampering with its internals. Used as component in metallic security seal.
holds the locking mechanism inside, has an angled conic shape in the cable-in orifice to ease insertion of cable.
2) Locking spheres:
3 sphere arranged in a triangular pattern that will hold the cable in place via pressure.
3) Wedge or bush:
Transfers the pressure of the spring to the spheres.
Stainless steel, made of wire 0.3 mm diameter, both ends closed has a controlled constant.
To close the assembly when it is ready. It is closed by pressing (min 10 kgf ) so the assembly cannot be dismantled easily without damaging it. The lid is colored in black or other distinctive color so the gripper to prevent inverted usage.
Technical Parameters of Cable Clip Wire Rope Clamp Cable Gripper
|Product name||adjustable cable gripper|
|Application||Hanging Lights;LED panel lights ect.|
|Suit for cable diameter||fit for 0.6mm~2.0mm steel wire|
|Delivery time||5~7 days|
Advantages of Cable Clip Wire Rope Clamp Cable Gripper
1.Aesthetically appealing and easy to handle.
Higher minimum breaking loads compared to teeth mechanism
2.Saves time in installation/alignment unlike traditional threaded rods/angles
Built-in pin for toolless adjustments.
3.Through a hole on all three models to make figure "8" double-loop assembly.
Tested for 5:1 load safety factor
About the application of Cable Clip Wire Rope Clamp Cable Gripper
Suspension Kits with adjustable cable grippers are the perfect alternative to the traditional threaded rod solution, they are used extensively throughout the building, architectural, lighting, and agricultural sectors.
With our many Cable Gripper styles you can hang anything: Drop Ceilings, Light Fixture Pendants, Signs, Displays, Shelves, Picture Frames, and more.
Custom order information of Cable Clip Wire Rope Clamp Cable Gripper
To start your order first, carefully review the product and service information on our drawing and quotation, if you don't see exactly what you want, please contact us regarding availability, size, and quantity requirements for your project. Make sure you have decided on exactly what you need.
Then, consult us on all your questions regarding
our products, components, and parts, because many of the components can be easily confused.
Contact us to receive a quote for your project.
After placing an order, the customer receives via fax or e-mail a Customer Order Acknowledgment, which indicates in detail descriptions of items and pricing. Orders will not be processed without WIRE ROPE MATE HARDWARE receiving a signed copy of said Customer Order Acknowledgment. Make sure to review and initial all areas. All changes to your orders of stock merchandise can be modified no later than 24 hours after receiving your order. We will call or fax you immediately should something change concerning your order.
Packaging Information of Cable Clip Wire Rope Clamp Cable Gripper
500 pieces in a plastic bag, and then into a carton.
By Air: 12kg per carton.
By Sea: 25kg per carton.
Using European standard wooden pallets, one pallet can hold up to 700kg.
International Shipping Around the World
All the Cable Clip Wire Rope Clamp Cable Gripper can be shipped worldwide by sea, by air or by international express logistics via DHL, FEDEX, UPS. You are welcome to get a free quotation by filling up the form with name, email, detailed address, product and requirements, we will shortly contact you with the full information including the most suitable delivery method (fast, secure, discreet) and freight.
What's the lead time?
Lead times will vary depending on the items and quantities on order. Normal lead times are 2-5 business days for stocked items. Please check with the Sales Team.
Are your products of good quality? How can I trust you?
Yes. We are a professional manufacturer of wire assemblies with 12 years producing experience in China .We have always been cooperating with domestic and overseas customers and partners with the first- class quality and service to make great achievements.
If this is your first time to contact us, please trust us, we’ll not let you down.
When can I get the price?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
