Wire Steel Lock Suspension Kits Display 3mm Aluminum Glass Shelf Cable Gripper For Sign
Product Details:
| Place of Origin: | Dongguan,China |
| Brand Name: | w-mate |
| Certification: | SGS,RoHS |
| Model Number: | WR2022052713 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PE bag +PP bag + carton (if you have other requirements, please contact us) |
| Delivery Time: | 10-15Work Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100,000pcs/month |
|
Detail Information |
|||
| Product Name: | Steel Cable Gripper | Material: | Brass |
|---|---|---|---|
| Cable Construction:: | 7x7 Or 7x19 | Application: | Lighting,hanging |
| MOQ: | 1000pcs | Lead Time: | 7 Days If There Were Enough Material In Stock |
| Sample: | Free Sample (Please Contact Our Customer Service) | ||
| High Light: | Glass Shelf Cable Gripper,Glass Shelf Adjustable Cable Grippers,Steel Grip Lock Cable Grippers |
||
Product Description
Detailed Information
Feature Of steel cable gripper
steel cable gripper, (also called cable slider or cable fastener):
Metallic component, cylindrical, external dimensions according to Annex 2, capable of gripping a wire rope of 7 x 7 wires via 3 sphere locking system. Grips cable when sliding in one direction and releases it on opposite direction. After cable is inserted provides no access to locking mechanism and no possibility of tampering with its internals. Used as component in metallic security seal.
Consists of:
1) Body:
holds the locking mechanism inside, has an angled conic shape in the cable-in orifice to ease insertion of cable.
2) Locking spheres:
3 sphere arranged in a triangular pattern that will hold the cable in place via pressure.
3) Wedge or bush:
Transfers the pressure of the spring to the spheres.
4) Spring:
Stainless steel, made of wire 0.3 mm diameter, both ends closed has a controlled constant.
5) Lid:
To close the assembly when it is ready. It is closed by pressing (min 10 kgf ) so the assembly cannot be dismantled easily without damaging it. The lid is colored in black or other distinctive color so the gripper to prevent inverted usage.
Technical Parameters of steel cable gripper
| Product name | steel cable gripper |
| Material | Brass |
| Thread Size | None |
| Cable Exit | Side Exit |
| Surface Treatment | 7x7 or 1x21 |
| Suit For Cable Diameter | Fit for 1.0mm,1.2mm,1.5mm cable or other |
| Weight Load | 20-100kg |
| Application | suspens kit for hang light |
| Delivery Time | 7 days after receive 30% down payment |
| Sample | Free Sample Available |
| MOQ | 1000pcs |
| Certification | SGS-RoHS |
Advantages of steel cable gripper
1. Easy to assemble:
Our cable gripper has automatic locking wire rope, which is very convenient for installation. The connecting parts can be simply assembled by bolts, and the bolts can only be loosened when you can disassemble them.
2. Reusability:
Compared with other metals, copper or aluminum has the advantage of reusability.
So when we dispose of it, it's easy to recycle, and it's easier to disassemble and assemble, so it can form a ministry product recycling system.
3. lightweight:
It is made of copper, iron, or aluminum alloy, so it is very light and convenient for transportation after assembly.
4. Artistry:
Due to the coating treatment of the formed surface, the occurrence of oxidation is reduced, corrosion resistance, scratch is not easy to form on the surface, and good glossiness is maintained at the same time.
Custom order information of steel cable gripper
Diameter:regular or customized
Thread Size:Regular or customized
Surface Treatment:Plating Chrome or Nickel
Color:Customized
Packaging Logo:Regular or customized
Delivery time (first delivery):3-7 working days for sample orders, 15-25 days for bulk orders
Payment method:T/T is 30%-70%
Payment methods:T/T, PayPal, etc.
Shipping port: FOB Shenzhen or FOB Shanghai
Minimum order quantity:1000pcs
Customers who bought steel cable gripper also bought
|
|
|
|
| Cable Gripper Light Suspension Kit | T Bar Clips | Wire Rope Sling | Adjustable Ceiling Clips |
Packaging Information
500 pieces in a plastic bag, and then into a carton.
By Air: 12kg per carton.
By Sea: 25kg per carton.
Using European standard wooden pallets, one pallet can hold up to 700kg.
International Shipping Around the World
All the Cable Gripper can be shipped worldwide by sea, by air or by international express logistics via DHL, FEDEX, UPS. You are welcome to get a free quotation by filling up the form with name, email, detailed address, product and requirements, we will shortly contact you with the full information including the most suitable delivery method (fast, secure, discreet) and freight.
FAQ:
What is a gripper?
A Cable Gripper is an adjustable fastener that automatically grips and locks to any position on an aircraft cable using an internal, spring-loaded 3-ball gripping mechanism. This allows the Gripper to move freely up the cable but not down unless the mechanism is released.
Can the cable gripper be customized?
Yes, we can make special customization according to your needs.
What types of Cable Grippers are available?
There’s a wide variety, but there are two distinct types.
The Straight-Thru’ or standard Gripper allows the cable to exit through the Gripper’s thread into the fixture.
The Side-Cable-Exit Gripper allows the cable to exit the Gripper from the side of the body before the Gripper enters the fixture, eliminating the possibility of a short circuit.
